← Plan a Garden with GardenCAD

Lesson 8: Refine, Save, and Share

Editing without redrawing, where your gardens actually live, and getting the plan onto paper or into someone else's hands.

GardenCAD
Lesson 08
Self-paced Lesson 08 of 08
Plan a Garden with GardenCAD

Refine, save, and share

Editing without redrawing, where the work actually lives, and getting it onto paper or into other hands.

Lesson
08 of 08
Lesson 08 · Refine and share
Learning objectives
GardenCAD
02 · 09
By the end of this lesson

You will be able to do three things.

01
Revise
Without redrawing: selection, vertex handles, nudging, restacking, and undo.
02
Keep
Your work safe: browser storage, an optional synced account, or exported JSON files.
03
Share
The plan as a printable scaled page with an inventory, or as a revocable read-only link.
Lesson 08 · Refine and share
Revising without redrawing
GardenCAD
03 · 09
Procedure · 5 habits

Five habits that make revision quick

01
of 05
Select
One, a group, or underneath
The select tool picks one. Drag on empty canvas to marquee a group. Alt-click cycles down through overlapping shapes.
Checkpoint · V selects
02
of 05
Drag
Handles, not new shapes
Every vertex has a handle. Arrow keys nudge the whole selection, and Shift makes the step larger.
Checkpoint · Nothing redrawn
03
of 05
Menu
Right-click a shape
Delete, duplicate, merge, and subtract, all without leaving the canvas or hunting through the rail.
Checkpoint · Menu open
04
of 05
Stack
Order overlapping regions
Control or command with the bracket keys moves a region forward or back. Add Shift for all the way.
Checkpoint · Order fixed
05
of 05
Undo
Experiment for free
Control or command with Z steps back, adding Shift steps forward. Nothing you try is expensive.
Checkpoint · Undo works
Lesson 08 · Refine and share
Where the work lives
GardenCAD
04 · 09
Storage · three options
This browser, by default
Gardens save automatically into local browser storage, which is why no account is needed. It is also why clearing your browser data would take them.
01
An EdQuest account syncs across devices and keeps a server backup. Gardens made before signing in upload automatically.
02
Export JSON writes a file you can archive or import into any other browser later.
03
Or keep the default and know the limit. The failure to avoid is assuming a backup you never turned on.
Lesson 08 · Refine and share
The printed plan
GardenCAD
05 · 09
Key fact · Output
The thing that goes outside

A printed plan with three question marks on it is more use in a garden centre than a perfect plan on a laptop at home.

Source GardenCAD print output: scaled landscape map plus a per-plant inventory table, printable separately
Lesson 08 · Refine and share
Four last traps
GardenCAD
06 · 09
Common mistakes · 4 of them

What goes wrong, and what to do instead

What goes wrong
What to do instead
01 · Loss A whole season's planning kept in one browser, then lost to cleared browsing data.
Instead Sign in for sync, or export a JSON file. At minimum, know which of the two you have not done.
02 · Redrawing Deleting and redrawing a bed because one corner is in the wrong place.
Instead Select it and drag the vertex handle. Arrow keys nudge, and undo makes experimenting free.
03 · Screenshots Sending a screenshot to somebody who wanted to look around the plan properly.
Instead Mint a read-only share link. It opens the live garden for anyone with no account, and you can revoke it.
04 · Shared plans Opening a garden somebody shared and trying to edit it, then wondering why nothing responds.
Instead Use Make a copy. You get your own editable version and the original stays exactly as it was shared.
Lesson 08 · Refine and share
Recap
GardenCAD
07 · 09
Recap · 3 takeaways
The whole course in three lines

What to remember

01
Set the site first. North and latitude are inherited by everything you draw, and every sun answer depends on them.
Lessons 01 and 06
02
Learn the one drawing gesture. Beds, structures, plantings, and traced fixtures all use it unchanged.
Lessons 02, 03 and 05
03
Read the light before you commit, then print it or share it. That is the part paper could never do.
Lessons 04, 06 and 07
Lesson 08 · Refine and share
Go further
GardenCAD
08 · 09
Where to look next

Where to learn more

Tag
Title & author
Format
Link
★ Core
The in-app tutorial and shortcut sheet Press the question mark key in the GardenCAD editor
Reference · opens beside the canvas
gardencad · press ?
★ Core
GardenCAD project documentation EdQuest Incorporated
Data model, solar model, sync
gardencad docs
Growing
Your regional planting calendar and frost dates Local extension service or equivalent
Calendars + zone maps
regional service
Growing
Seed supplier catalogues Any supplier you actually buy from
Spacing + days to maturity, by variety
supplier catalogue
Next
The rest of the EdQuest class catalogue EdQuest Incorporated
Self-paced courses
edquest · classes
GardenCAD
Lesson 08 of 08 · Complete
End of class

Set north, draw one bed, and check the light.

Ten minutes on your own plot will teach you more than rewatching any of this. The plan will be wrong the first time, which is the whole reason to have it somewhere you can change it for free.

Course
Plan a Garden with GardenCAD
Lessons
8
Next step
Open the editor and set north
Read along Synthesized voice

Last lesson. Your garden is drawn, planted, and audited, and it exists in exactly one place: this browser, on this device. That is a deliberate design choice and it means you could start planning without signing up for anything, but it is worth understanding properly, because clearing your browser data would take the lot. So this lesson covers three things. Editing without redrawing, which is the set of habits that make revising a plan quick rather than tedious. Where the work actually lives and what your options are for keeping it safe: automatic local saving, an optional EdQuest account that syncs across devices, and JSON files you can export and archive yourself. And getting the plan out: a scaled printable page with a plant inventory, and a read-only link you can send to somebody who does not have an account.

Read along Synthesized voice

Three objectives. First, you will be able to revise a plan without redrawing it: select single objects or a marquee of them, drag vertex handles, nudge with the arrow keys, restack overlapping regions, use the right-click menu, and undo anything with the standard shortcut. Second, you will be able to say where your gardens live and choose how to keep them: automatic saving into this browser, an optional EdQuest account that syncs across devices and keeps a server backup, or an exported JSON file you archive yourself. Third, you will be able to get the plan out of the screen: a scaled printable page with a legend and a per-plant inventory you can take to the nursery, and a read-only share link that anybody can open without an account and that you can revoke later.

Read along Synthesized voice

Five habits that make revision quick. First, select properly: the select tool picks one object, dragging on empty canvas marquees a group, and holding Alt while clicking cycles down through a stack when shapes overlap. Second, drag handles rather than redrawing: every vertex of a region has one, and the arrow keys nudge a whole selection with Shift for a larger step. Third, use the right-click menu, which carries delete, duplicate, and the merge and subtract operations from Lesson two. Fourth, manage the stack: control or command with the bracket keys brings a region forward or sends it back, and adding shift takes it all the way to the front or the back. Fifth, undo freely. Control or command with Z steps back and adding shift steps forward again, so experimenting costs you nothing.

Read along Synthesized voice

Where does a garden actually live? By default, in this browser, saved automatically as you work. That is why you could start planning within seconds of arriving without an account, and it is genuinely the right default. It also means clearing your browsing data, or switching to a different device, would leave the plan behind. You have three ways to deal with that and they are not exclusive. Sign in with an EdQuest account and your gardens sync across devices with a server backup, and anything you made before signing in uploads automatically rather than being lost. Export a JSON file for anything you want archived independently, which you can import back into any browser later. Or accept the default and simply know the limitation. What is worth avoiding is assuming a cloud backup that you never actually turned on.

Read along Synthesized voice

The printed plan deserves a slide of its own because it is the thing that actually goes outside with you. It is a scaled, to-page drawing of the garden with a legend, and alongside it a per-plant inventory table listing every species and how many of each. You can print the map and the table together, or just the table on its own, which turns it into a tick-box shopping list to take to the nursery. That is the point where a plan stops being a screen and starts being a thing you use with muddy hands, and it is worth generating even for a garden you consider unfinished. A printed plan with three question marks on it is more use in a garden centre than a perfect plan on a laptop at home.

Read along Synthesized voice

Four last traps. People plan a whole season in one browser and lose it to a cleared cache: sign in, or export a file, or at minimum know that you have not. People redraw a bed to move one corner: drag the handle. People send a screenshot of the plan when they want someone else to look at it, which cannot be zoomed or read properly: mint a read-only share link instead, which opens live for anyone with no account and can be revoked whenever you like. And people receive a shared garden, start editing it, and discover it is read-only: use make a copy, which gives you your own editable version without touching the original that was shared with you.

Read along Synthesized voice

Three things from this lesson, and then three for the course. From this lesson: revise rather than redraw, because handles, nudging, restacking, and undo between them mean almost nothing needs to be made twice. Decide where your work lives before you need to know, because the default is local and that is fine only if it is a choice. And get the plan out of the screen, onto paper for the nursery or into a share link for whoever is helping you. For the course: set the site first, because everything inherits it. Learn the one drawing gesture, because everything reuses it. And read the light before you commit, because that is the part a plan on paper could never do for you.

Read along Synthesized voice

Five places to go next. The in-app tutorial is the fastest reference: press the question mark key in the editor any time and it opens beside the canvas while the app stays usable, with a keyboard shortcut sheet behind it. The GardenCAD project documentation covers the data model and the solar model in detail, including how shadows are projected and how sun hours are integrated. For the horticulture rather than the software, your regional extension service or equivalent publishes planting calendars and frost dates that will be more specific than any general catalogue. A seed supplier catalogue is worth reading for spacing and days to maturity for the varieties you actually buy, since those differ from generic entries. And the EdQuest class catalogue has the other courses in this series.

Read along Synthesized voice

That is the course. You have set a real site with a real orientation, drawn beds and structures, traced an existing garden to true scale, chosen species and queued what you meant to grow, filled the beds by hand and automatically, audited the light across a season, and got the result onto paper and into a shareable link. Every tool in the editor has now turned up in the situation it was built for. Do one thing before you close this: open your own plot, set north, and draw one bed. Ten minutes of a real garden will teach you more than rewatching any of these lessons, and the plan is going to be wrong the first time regardless, which is exactly why it is worth having somewhere you can change it for free.
